SRPL-2309-24-75CVT

SRPL-2309-24-75CVT Expand

20316

New

In stock
Quantity:
Order quantity: 1 шт

4 240,00 ₴

/ Штука

Need help? (consultation, payment, delivery)
Short description
RF receiver driver for controlling single-color LED strips with a voltage of 24VDC, using RF remotes, panels, PushDim buttons, or a mobile app on iOS and Android devices. The power supply voltage of the driver is 220VDC. Two parallel output channels with a total load of 3.12A.
Manufacturer: SUNRICHER
Input Voltage, V ? 100-240VAC
Warranty term ? 3 years
Number of Output Channels ? 2 channels
Денис
Денис
менеджер
Viber
Пн-Пт 9:00 - 18:00
Delivery across Ukraine Delivery in Kyiv Pickup Payment Warranty

Delivery is carried out by Nova Poshta.

For orders over 5000 UAH, delivery to the branch is free of charge.

The cost of home delivery is paid by the Customer.

Learn more

The company's courier service can deliver orders within Kyiv and the suburbs (up to 15 km).

The delivery cost is agreed upon with the manager.

For orders over 5000 UAH, delivery is free of charge.

Learn more

Pickup of paid goods is carried out from the company's office at the address: Kyiv, Vaclav Havel Boulevard, 8 "BC Xspace".

Pickup schedule: Mon–Fri, from 8:00 to 18:00

Learn more

Payment for goods is made in a non-cash form.

Non-cash payment can be made both with VAT and without VAT.

Payment can also be made via the LiqPay payment system on our website.

Learn more

The standard warranty for SVL luminaires is 5 years.

All products of other brands are covered by the manufacturers' warranties, the terms of which are specified in the product documents.

The warranty is valid provided that the operating conditions are observed and the required documents are available.

Learn more...

Hide
SRPL-2309-24-75CVT

20316

In stock
Quantity: шт

4 240,00 ₴

Parameters SRPL-2309-24-75CVT

Input Voltage, V ? 100-240VAC
Warranty term ? 3 years
Brand ? SUNRICHER
Number of Output Channels ? 2 channels
Maximum Current per Channel, A/сh. ? 3.0
Data (Signal) RF-пульт
Case Type ? metal

Description SRPL-2309-24-75CVT

RF receiver-driver for controlling single-color LED strips with a voltage of 24VDC, using RF remotes, panels, PushDim buttons, or a mobile app on iOS and Android devices. The power supply voltage of the driver is 220VDC. Two parallel output channels with a total load of 3.12A.
  • Suitable for dimming LED strips with a supply voltage of 24VDC.
  • Two parallel output channels with a total load of 3.12A/75W.
  • For single-color LED strips.
  • Compatible with RF remotes and panels for controlling RF receivers of the 1009XX series.
  • When using a WiFi/RF converter, it is controlled via a mobile app on ANDROID and iOS devices.
  • Possible control using PushDim (bell button).
  • Ultra-thin design 486x20.9x30.7mm suitable for use in linear luminaires.
  • Metal housing.
  • High reliability with protection against short circuits, overloads, and overheating.
  • 5 years warranty.
